Description: Connect an a500 keyboard controller daughter board to an a1200 keyboard MPU. Solder directly or use a PLCC socket.
Picture Stats: Views: 3698 Filesize: 38.47kB Height: 768 Width: 1024 Posted by: willow at February 10, 2007, 01:07:58 PM Image Linking Codes
|
||
| 0 Members and 1 Guest are viewing this picture. |
| Piru Posts:6946 | February 10, 2007, 08:50:54 PM Yes, this works fine. I took +5 and GND elsewhere, and soldered the CLK and DAT to CIA instead, but basically it's the same. This version has the benefit of having all wires to single chip so it makes things easier (esp if you use reversed socket). However, I had to cut the original chip's CLK and DAT, or the hack would not work. |
| Jope Posts:1172
| February 10, 2007, 06:27:05 PM Yes, it does. If your A500 keyboard has only one flat cable, you can plug the controller board directly to the A1200 keyboard's flat cable and then just solder according to the diagram. |
| Ilwrath Posts:2199 | February 10, 2007, 05:07:19 PM interesting. does this fix the multi-keypress lockouts? |
